Home>Magnetic Drilling Machines>Magnetic Drilling Machines 8840 Maximum drilling diameter 40mm 1500V Professional grade Adjustable Speed
Magnetic Drilling Machines 8840 Maximum drilling diameter 40mm 1500V Professional grade Adjustable SpeedItem NO.: M_8840
USD 280.00
- Quantity
-
Free Shipping
Adding to cart succeed
Magnetic Drilling Machines 8840 Maximum drilling diameter 40mm 1500V Professional grade Adjustable Speed
color:red,size:xxl
Subtotal: USD 0
View My Cart
- This 1500W heavy-duty mag drill bores at 0-650 RPM stepless speed up to a maximum 50mm depth and a maximum 40mm across. Powerful motor, the magnetic drill press drills through industry quality steel with ease.
- Coolant tank, dustproof air inlet, and exhaust air holes are designed for cooling the magnetic drill press during overheating. Coolant tank is used for fast heat dissipation.
- Travel distance: 230mm. Both side of the mag drill can be installed with 3 extended crank handles for adding your convenience. This ergonomic design handle provides comfortable grip in operation and transport. Double Dovetail Guide Rail: The double dovetail guide rail can adjust the height of the motor to get a max.
- The powerful two-stage magnet can generate 12,000 N of holding force, ensuring the drill press machine will not move in the work. Thanks to its Electromagnet base, our magnetic drill press anchor itself securely during use through its solid iron bottom.
- Various Applications: This versatile magnetic drill press is immensely suitable for industrial and steel fabrication, ship or bridge building, railway manufacture, wind power generation, power-plant construction, home improvement, equipment installation, and a wide swath of other fields.
-
- Product Name: Magnetic Drilling Machines 8840 Maximum drilling diameter 40mm 1500V Professional grade Adjustable Speed
- Item NO.: M_8840
- Weight: 11 kg = 24.2508 lb = 388.0136 oz
- Category: Magnetic Drilling Machines
- Creation Time: 2022-11-15
OverviewProduct model 8840 Maximum drilling diameter 40mm Rated voltage 110v/220v Rated frequency 50/60Hz Rated power 1500W Maximum No-load speed 650r/min Magnetic seat suction 12000N Stroke 120mm Adjustable stroke 230mm Max cutting depth 50mm Annular cutter diamater 40mm Machine net weight 11Kg Drill chuck Ø19.05 mm (Ø3/4") Dimensions 110x270x350mm Tapping diameter 16mm Features Overload protection √ Integrated cable routing √ Package Inclusions Magnetic drilling machine 1 pc Pilot pin 1 pc Mesh belt 1 pc Geared drill chuck 1 pc M10 Hex key or 1 pc M12 Hex key Carrying case 1 pc Operating manual 1 pc Warranty Certificate 1 pc Sutible adapter Morse taper sleeve √ Drill chuck arbor √ Drill chuck √ Morse Taper Shank Arbor of Annular Cutter √
Customer Reviews
C****H2022-12-13
This unit has lots of power and the company does make a great product. I told my friend about this and he bought the one that they sell which is as good as mine but operates at the slower speed for cutting metal. Now he can use mine for the smaller holes and i can use his for the larger holes. the larger the hole the slower the speed. In all cases you must use lots of cutting fluid to keep drill bit sharp and cooled. Great buy.
